FRP Fiber Glass Ventilation Exhaust Cooling Axial Fan Cooler/Blower/Centrifugal Fans/for Poultry House/Greenhouse/Industrial/Workshop/ Axial Fan Equipment

We are a technology-driven company focusing on promoting the update and upgrade of the High Pressure Centrifugal Fan, Tunnel Fan, Rotary Axial Fan. Our strong market competitiveness comes from the strong comprehensive strength of enterprises. At present, our marketing outlets are all over the country, and the professional service team provides 'whole process worry free service' for customers. Honesty and integrity are the manifestation of good character. Being a person and doing things with integrity will accumulate more wealth for us. We are in line with the 'product is the best spokesperson' the purpose of serving customers, adhering to the 'professional, large-scale, international' development direction and has been the care and love of people from all walks of life. We will be pleased to give you a quotation upon receipt of one's detailed specifications.

Booster Fan Duct Booster Fan:

Booster fan duct booster fans are generally used in forging furnaces and high-pressure forced ventilation. The gas does not contain viscous substances, the dust and hard particles contained do not exceed 150mg/m3, and the gas temperature is 20-800 °C.
Booster fan duct booster fans can fansfan be made into two types: right-handed and left-handed. From the side of the motor, if the impeller rotates clockwise, it is called a right-handed fan, denoted by "right"; the impeller rotating counterclockwise is called a left-handed fan, denoted by "left".
The position of the air outlet of the fan is expressed by the angle of the air outlet of the casing. "Left" and "Right" can be made into six angles of 0°, 45°, 90°, 135°, 180°, and 225°.
Before installation: All parts of the fan should be checked comprehensively, whether the parts are complete, whether the rotation direction of the impeller and the casing are consistent, and whether the connection of each part is tight. Whether the impeller, main shaft, bearing, and other main parts are damaged, whether the transmission group is flexible, etc.

When installing: pay attention to checking the casing, and there should be no tools and debris left in the casing. To prevent rust and reduce the difficulty of disassembly on some joint surfaces, some grease or mechanical oil should be coated. The connection surface between the fan and the foundation, the inlet, and the outlet ducts should be adjusted to match naturally, and the connection should not be forced and is not allowed to add the weight of the duct to each part of the fan. And pay attention to ensure the horizontal position of the fan.

Booster fan duct booster fan installation requirements:
(1) Install according to the position and size are shown in the drawing. To ensure high efficiency, ensure the axial and radial clearance between the air inlet and the impeller.
(2) After installation, try dialing the transmission group to check whether it is too tight or collides with the fixed part.
(3) After all installations are completed and the general inspection is passed, the test operation of the fan can be carried out.
To prevent the motor from being overloaded and burned, when the fan starts, it must be carried out under no load (close the air inlet valve and open the air outlet valve slightly). If the condition is good, gradually open the valve until the specified working condition. During operation, the current should be strictly controlled and the rated value should not be exceeded.

In order to meet the strict quality requirements of customers, we have been committed to improving production capacity and management level, so that the quality of FRP Fiber Glass Ventilation Exhaust Cooling Axial Fan Cooler/Blower/Centrifugal Fans/for Poultry House/Greenhouse/Industrial/Workshop/ Axial Fan Equipment can be more effectively controlled and guaranteed during the production process. We insist on 'survive by quality, development by efficiency'. At the same time, we also have good cooperation and exchanges with some large international companies, and have been unanimously recognized and affirmed by them.
